ORTUR Laser Engraving Cutting Machine CNC Roller Rotary DIY Printer Graving Tool Powerful Woodworking Metal Wood Leather Acrylic

Features:

Engraving Area:400MM×400MM

Wave Length:445±5nm

Focus:Fixed Focus

Default Focal Length:50mm (from the heat sink to the object)

Control Mode:PWM

Power Rate:S0-S1,000

Output Powerful:1.6W-10W

Engraving Speed:0-15000MM/Min

Baud Rate:115200 – 921600 (Default: 115200)

Computer OS:Win XP, Win 7, Win 8, Win 10 (LaserGRBL),Mac and Linux (LightBurn)

Control Softwares:LaserGRBL (free), LightBurn (Paid Software)

Input Format:JPG, JPEG, PNG, BMP, SVG, etc.

Available Materials of Engraving:Wood Board, Paperboard, Black Acrylic, Leather, Food, Stainless Steel, Power Coated Metal, etc.

Available Materials of Cutting:Wood Board, Paperboard, Black Acrylic, Leather, Felt Cloth, Dark Color Plastic Sheet (Melt), etc.

Input Voltage:110V-220V (Compatible)

Power Adapter Output:24V / 2A

Operating Temp:-20℃-50℃

Advantage:

1. Don’t worry about quality problems, the product has a one-year warranty period, and parts are damaged for free replacement

2. We have CN US ES RU overseas warehouse, you can receive the product within 3-15 days

3.Increases the maximum speed to 15000mm/min.

4.Aluminum profile frame, solid structure, smooth operation.

5.4 Safety protection:Active position protection, sloping position protection, flame detector and buzzer alarm and emergency stop switch for an emergency.

TIPS:

LU2-10A:More Powerful Engraving with True 10W Output Power LU2-10A is newly upgraded with a 10W laser module, which makes the cutting speed up to 15,000 mm/min. The compressed point is 0.05mm x 0.1mm.The optical power reaches to 10W. It can cut 30mm acrylic and 20mm wood. At the same time, the laser module of the engraving machine has a built-in air-assist interface, which is designed for cutting.

LU2-4-LF
long focus laser module of the laser engraver has a real luminous power of 4,500-5,500mw and 0.17 x 0.25mm focal spot. With high power and a long depth of field, it is good for engraving and cutting.

Note: The module can work with an air compressor (not included in the package) for enhanced performance. recommends an air source with a flow of ＞40ml/min.

LU2-2
fixed focus laser module of the laser engraver has a real luminous power of 1,000-1,600mw and 0.07 x 0.06mm focal spot, perfect for engraving high precision patterns.

LU2-4-SF
short focus laser module of the laser engraver has a real luminous power of 4,500-5,500mw and 0.12 x 0.15mm focal spot. With high power compressed spot, it is good at cutting and better at engraving hard materials.
